Audio Port For Mac



Information about these and other types of Mac ports is in the specifications for your Mac: Choose Apple menu  > About This Mac, click Support, then click Specifications. Or check your Mac user guide.

Thunderbolt 3

Use Thunderbolt 3 with displays and other devices that connect using either a Thunderbolt 3 cable or USB-C cable. You can also connect a USB-C power adapter and cable to charge your notebook computer. If you have a device that doesn't connect to this port, you might be able to use an adapter to connect it.

These Mac models have Thunderbolt 3 ports:

PortAudio port for mac mojave
  • MacBook Pro introduced in 2016 or later
  • MacBook Air introduced in 2018 or later
  • iMac introduced in 2017 or later
  • iMac Pro (all models)
  • Mac mini introduced in 2018
  • Mac Pro introduced in 2019

When designing the smaller Mac Pro I suspect that Apple looked at the old Pro models and considered which ports were used by the fewest number of people. Clearly the optical audio in and out ports. Check your ports: Disconnect anything that is plugged into your Mac - not just from the audio port as Thunderbolt, HDMI, and USB devices could be channelling the audio. If there is just a cable. Analog audio out: You can use this port to connect self-powered speakers, MP3 and CD devices, and other audio equipment to your Mac. Optical digital audio in and out: You can use these ports to transfer stereo or encoded 5.1 audio using the S/PDIF protocol over Toslink cables and connect to decks, receivers, digital instruments, and 5.1.


If your Mac notebook or desktop computer has more than one port like this, each port supports ThunderBolt 3 and USB-C.

For

USB-C

Use USB-C with displays and other devices that connect using a USB-C cable. You can also connect a USB-C power adapter and cable to charge your notebook computer. If you have a device that doesn't connect to this port, you might be able to use an adapter to connect it.

MacBook models introduced in 2015 or later have a single USB-C port. This port doesn't support Thunderbolt devices.


If your Mac has only one port like this, it's a MacBook that supports USB-C but not Thunderbolt.

Thunderbolt

Use Thunderbolt or Thunderbolt 2 with displays and other devices that connect using a Thunderbolt cable.

These Mac models have Thunderbolt or Thunderbolt 2 ports:

  • MacBook Pro introduced in 2011 through 2015
  • MacBook Air introduced in 2011 through 2017
  • Mac mini introduced in 2011 through 2014
  • iMac introduced in 2011 through 2015
  • Mac Pro introduced in 2013

Thunderbolt and Thunderbolt 2 are not the same as Mini DisplayPort . They have the same shape, but use different symbols on the cable and port. However, this port does support Mini DisplayPort for video output, so you can use a Mini DisplayPort cable to connect a Mini DisplayPort display.

Mini DisplayPort

Use Mini DisplayPort with displays that connect using a Mini DisplayPort cable.

These Mac models have Mini DisplayPort:

Audio Port For Mac
  • MacBook Pro introduced in late 2008 through 2010
  • MacBook Air introduced in late 2008 through 2010
  • Mac mini introduced in 2009 and 2010
  • iMac introduced in 2009 and 2010
  • Mac Pro introduced in 2009 through 2012

Mini DisplayPort is not the same as Thunderbolt or Thunderbolt 2 . They have the same shape, but use different symbols on the cable and port.

USB-A

Use USB-A with devices that connect using a USB cable. USB ports are sometimes known by the USB specification of the port, such as USB 2 or USB 3.


Left to right: power, two Thunderbolt, USB-A, and Audio-Out.

HDMI

Use HDMI with displays and TVs that connect using an HDMI cable.

Audio Port For Mac Windows 10

Ethernet

Use Ethernet with networks and devices that connect using an Ethernet (RJ45) cable.

FireWire

Use FireWire with devices that connect using a FireWire 400 or FireWire 800 cable.

SD card

Use the SD card slot with SD, SDHC, SDXC, MMC, and UHS-II media cards, such as those used by digital cameras.

Audio

Use Audio-Out — or — with headphones, speakers, and other audio-output devices that connect using an audio cable that has a 3.5 mm (1/8 inch) audio jack.

Audio Port For Mac Catalina

Use Audio-In with a microphone or other audio-input device that connects using an audio cable that has a 3.5 mm (1/8 inch) audio jack.

Audio Port Mac

Power

Use the power port , if available, to connect your computer to AC power using a MagSafe cable or adapter. This port isn't available on newer Mac notebook computers, which use Thunderbolt 3 or USB-C for power and charging. Learn more about power adapters and cables for Mac notebook computers.

Audio Port For Mac High Sierra

Port

Audio Port For Macbook Air

Learn more
